Reefs RC Aluminium 422HDv2 Standard 35kg 8.4V Coreless Metal Gear Winch Servo with Spool - Black
Reefs RC Aluminium 422HDv2 Standard 35kg 8.4V Coreless Metal Gear Winch Servo with Spool - Black
Brand:
Reefs RC
|
SKU: REEFS43
$228.29
Pay later with
Description
No description
Specifications
Servo
-
Total Length
- 54.12mm
-
Total Width
- 20.44mm
-
Drive Motor Type
- Coreless
-
Top to Under Mount
- 16.25mm
-
8.4V Sec/60 Degrees
- 0.09
-
Input Voltage Range
- 7.4V, 6V, 8.4V
-
Rotational Degrees
- 360°
-
8.4V Torque kg/cm
- 35
-
Signal Type
- Digital
-
Case Material
- Aluminium
-
6V Torque kg/cmKilograms of torque at 25mm away from the center of the spline
- 29
-
Gear Material
- Steel
-
Waterproof Casing
- Yes
-
Servo Spline Count
- 25Tooth
-
6V Sec/60 DegreesSeconds per 60 degrees of rotation
- 0.11
-
7.4V Torque kg/cm
- 32
-
Total Height
- 43mm
-
7.4V Sec/60 Degrees
- 0.10
-
Body Length
- 40.05mm
-
Bottom to Under Mount
- 25.58mm
-
SizeConventionally sized servo names
- Standard
