Savox 32kg 8.4v Low Profile HV Brushless Servo
Videos
Savox 32kg 8.4v Low Profile HV Brushless Servo
Servos are powered by the ESC's output to the receiver. If you're using a higher-strength servo than the ESC can support (usually greater than 20kg), you may experience 'brown-outs' where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver smoothing the current delivery. However, in some cases, you may need to install an external BEC.
The Savox SB-2267SG Plus stands out as a high-torque, steel-geared, digital, low-profile servo boasting an all-black finish for a stealthy look in RC cars. It serves as an ideal upgrade for standard, plastic-geared servos providing limited torque.
- Leading edge digital servo technology
- Strong 3-Pole Brushed motor
- Accurate and fast response
- Ball bearings provide fluid and unrestricted movement
- Precision Steel gears are durable and long lasting
- Spline size: 25T Spline
- Servo Technology: Digital High Voltage
- Operating Voltage (V): 7.4V - 8.4V
- Motor Type: Brushless Motor
- Weight: 57g
- Gear Type: Steel Gears
- Servo Case: Black Plastic
- Torque @ 7.4v: 25.0kg-cm (347.2 oz-in)
- Torque @ 8.4v: 32.0kg-cm (444.4 oz-in)
- Speed @ 7.4v: 0.08 sec/60 deg
- Speed @ 8.4v: 0.065 sec/60 deg
- Connector type: JR/Futaba
- Total Height (A) = 26.05mm
- Body Width (B) = 40.8mm
- Below Mount (C) = 17.1mm
- Above Mount (D) = 8.95mm
- Total Length (E) = 54mm
- Total Width (F) = 20.2mm
In this video, Hamish gives a step-by-step guide on installing a Servo and how to avoid stripping your servo gears.
-
8.4V Torque kg/cm
- 32
-
Servo Spline Count
- 25Tooth
-
7.4V Torque kg/cm
- 25
-
Total Length
- 54mm
-
Total Width
- 20.2mm
-
Input Voltage Range
- 7.4VV, 8.4VV
-
Drive Motor Type
- Brushless
-
Total Height
- 25.55mm
-
Body Length
- 40.8mm
-
Case Material
- Aluminium
-
Rotational Degrees
- 120° (Normal)
-
Signal Type
- Digital
-
Gear Material
- Metal
-
Waterproof Casing
- Yes
-
7.4V Sec/60 Degrees
- 0.08
-
Bottom to Under Mount
- 16.6mm
-
8.4V Sec/60 Degrees
- 0.065
-
Top to Under Mount
- 8.95mm
-
SizeConventionally sized servo names
- Low Profile
