HSP Standard Metal Geared Waterproof Servo 9Kg
HSP Standard Metal Geared Waterproof Servo 9Kg
Brand:
HSP
|
MPN: SP9001
This product has been replaced by the product below.
Compatible with
120 products.
See Compatibility
Recommended Products
Related Products
Description
Servos are powered by the ESC's output to the receiver. If you are using a higher-strength servo than the ESC can support (usually greater than 20kg), you may experience brown-outs where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver to smooth the current delivery. However, in some cases you may need to install an external BEC.
Specifications
-
Model
- HSP-SP9001
-
Total Height (A)
- 45.5mm
-
Body Width (B)
- 40mm
-
Below Mount (C)
- 27mm
-
Above Mount (D)
- 18.5mm
-
Total Length (E)
- 53.5mm
-
Total Width (F)
- 20mm
Servo
-
SizeConventionally sized servo names
- Standard
-
Gear Material
- Metal
-
Servo Spline Count
- 25Tooth
-
Waterproof Casing
- Yes
-
Case Material
- Metal
-
Height (A)
- 45.5mm
-
Body Length (B)
- 40mm
-
Bottom to Under Mount (C)
- 27mm
-
Top to Under Mount (D)
- 18.5mm
-
Length (E)
- 53.5mm
-
Width (F)
- 20mm
-
Rotational Degrees
- 120° (Normal)
-
6V Torque kg/cmKilograms of torque at 25mm away from the center of the spline
- 9
-
6V Sec/60 DegreesSeconds per 60 degrees of rotation
- 0.14
