Savox Black Edition SB-2295SG Standard 40kg 8.4V Digital Metal Geared Brushless Servo
Servos are powered by the ESC's output to the receiver. If you're using a higher-strength servo than the ESC can support (usually greater than 20kg), you may experience 'brown-outs' where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver smoothing the current delivery. However, in some cases, you may need to install an external BEC.
The powerhouse "Monster" performance series from Savox, meticulously crafted with a rugged all-aluminium casing and equipped with innovative brushless motor and controller technology, unleashes a remarkable 35% power boost over its predecessors.
- Leading edge digital servo technology
- Strong 3-Pole Brushed motor
- Accurate and fast response
- Ball bearings provide fluid and unrestricted movement
- Precision Steel gears are durable and long lasting
- Spline size: 25T Spline
- Servo Technology: Digital High Voltage
- Operating Voltage (V): 7.4V - 8.4V
- Motor Type: Brushless Motor
- Weight: 79 g
- Gear Type: Steel Gears
- Servo Case: Anodised Black & Silver Aluminium Case
- Ball Bearings: 3 Precision Ball Bearings
- Speed 60°/Sec @ 7.4V: 0.07sec/60 deg
- Speed 60°/Sec @ 8.4V: 0.050 sec/60 deg
- Torque kg/cm @ 7.4V: 32.0kg/430.5oz-in
- Torque kg/cm @ 8.4V: 40.0kg/624.9oz-in
- Connector type: JR/Futaba
- Total Height (A) = 42.7mm
- Body Width (B) = 40.3mm
- Below Mount (C) = 25.9mm
- Above Mount (D) = 11.7mm
- Total Length (E) = 54mm
- Total Width (F) = 20.2mm
In this video, Hamish gives a step-by-step guide on installing a Servo and how to avoid stripping your servo gears.
| Servo | |
|---|---|
| Size: | Standard |
| Gear Material: | Metal |
| Waterproof Casing: | Yes |
| Servo Spline Count: | 25tooth |
| Signal Type: | Digital |
| Input Voltage Range: | 7.4V, 8.4V |
| Drive Motor Type: | Brushless |
| Case Material: | Metal |
| Rotational Degrees: | 120° (Normal) |
| Total Height: | 38.7mm |
| Total Length: | 40.3mm |
| Total Width: | 20.2mm |
| 7.4V Torque kg/cm: | 32 |
| 8.4V Torque kg/cm: | 40 |
| 7.4V Sec/60 Degrees: | 0.06 |
| 8.4V Sec/60 Degrees: | 0.05 |
