Traxxas Standard Waterproof 5.76kg Servo

Brand: Traxxas | SKU: 2056

1 in stock

1.0

1 reviews

$86.15

Pay later with

Want more than 1?

and we'll notify you when the stock is here.

We'll send it today

When ordered within the next hms

Delivery Options

Part Support

Shop replacement & upgrade parts for this model

Shop Parts

Compatibility

Description

Servos are powered by the ESC's output to the receiver. If you're using a higher-strength servo than the ESC can support (usually greater than 20kg), you may experience 'brown-outs' where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver smoothing the current delivery. However, in some cases, you may need to install an external BEC.

TRA-2056 Servo Specifications

Total Height (A) = 42.5mm
Body Width (B) = 40.2mm
Below Mount (C) = 27mm
Above Mount (D) = 15.5mm
Total Length (E) = 54.8mm
Total Width (F) = 19.7mm

Specifications

Servo

Servo Spline Count: 25Tooth
Total Length: 54.8mm
Total Width: 19.7mm
Bottom to Under Mount: 27mm
Top to Under Mount: 15.5mm
Total Height: 42.5mm
Body Length: 40.2mm
Rotational Degrees: 120° (Normal)
6V Sec/60 Degrees Seconds per 60 degrees of rotation: 0.23
Signal Type: Analog
Case Material: Plastic
6V Torque kg/cm Kilograms of torque at 25mm away from the center of the spline: 5.76
Gear Material: Plastic
Waterproof Casing: Yes
Drive Motor Type: Brushed
Size Conventionally sized servo names: Standard

Parts

Standard

Traxxas Servo Case w/ Gaskets

0 reviews

$16.94

Shop Parts

Shop replacement & upgrade parts for this model.

Reviews (1)

Aug 04, 2025

dennis P

Verified Buyer

I was invited to rate this product. It is a replacement for the same servo, that just stopped working. For a Traxxas Mini Max that just keeps breaking things. The RC is always operated on "training mode, 50% power" But it has spent more time broken, then running. Hobbies Direct is great to get parts, however, parts for this RC is sparse, and am sometimes ordering parts overseas. I am sorry I bought it now.
