ARRMA Standard ADS-15M 15Kg Waterproof Metal Geared Servo

Brand: ARRMA | SKU: AR390139

sold out

write a review

$123.59

On Order Since Nov 20, 2025

The date we ordered this product from our supplier.

Delivery Options

Part Support

Shop replacement & upgrade parts for this model

Shop Parts

Compatibility

Description

Servos are powered by the ESC's output to the receiver. If you're using a higher-strength servo than the ESC can support (usually greater than 20kg), you may experience 'brown-outs' where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver smoothing the current delivery. However, in some cases, you may need to install an external BEC.

Overview:

The ADS-15M V2 Servo is designed to give you fast and precise steering. Resilient to the elements and built from hard-wearing materials.

Specification:

Case – Red, Water-proof & dust-proof

Bearing – Dual ball bearing

Connector – ‘Futaba style’ 3 pin connector

Gears – Metal

Spline – 25 Tooth

Dimensions: 40mm x 38mm x 20mm (Excluding mounting tabs), Industry Standard size

Wire length: 300mm

Torque – ADS-15M: 15kg-cm (208oz-inch) at 7.2V, 14kg-cm (195oz-in) at 6.0V

Speed – 0.14 sec/60 deg at 7.2V, 0.16 sec/60 deg at 6.0V

Signal – Analogue

Specifications

Servo

Total Width: 20mm
Servo Spline Count: 25Tooth
Top to Under Mount: 15mm
Total Length: 54mm
Body Length: 40mm
Bottom to Under Mount: 28mm
6V Sec/60 Degrees Seconds per 60 degrees of rotation: 0.14
Total Height: 43mm
Case Material: Plastic
Rotational Degrees: 120° (Normal)
Signal Type: Analog
6V Torque kg/cm Kilograms of torque at 25mm away from the center of the spline: 15
Gear Material: Metal
Waterproof Casing: Yes
Size Conventionally sized servo names: Standard
