HSP RC4 1040 Waterproof Brushed ESC w/ Receiver & LED Light Controller (3 in 1)

HSP RC4 1040 Waterproof Brushed ESC w/ Receiver & LED Light Controller (3 in 1)

HSP RC4 1040 Waterproof Brushed ESC w/ Receiver & LED Light Controller (3 in 1)

Brand: HSP | MPN: HW-711
1 in stock
$53.85
or 4 fortnightly payments of $13.46 with Afterpay

HSP RC4 1040 waterproof 3-in-1 unit combining a brushed ESC, 2.4GHz receiver, and LED light controller for 1/10 scale RC vehicles.

  • 3-in-1 unit: brushed ESC, 2.4GHz receiver, and LED light controller
  • Waterproof for all-weather use
  • 40A continuous / 200A peak current
  • Compatible with 2-3S LiPo or 5-9 cells NiMH
  • Designed specifically for HSP RC4 1/10 scale vehicles
Select Male Connector
Deans
Deans
EC3
EC3
+ $5.50
XT60
XT60
+ $5.50
Other - Leave Comment
Other - Leave Comment
+ $5.50
Other - Leave Comment
Add to Wishlist
Pay later with
Afterpay Zip Paypal

Want more than 1?
and we'll notify you when the stock is here.
Enter your suburb or postcode for delivery options
or
Enter your country for international delivery options
Description

The HSP RC4 1040 Waterproof Brushed ESC with Receiver and LED Light Controller (3 in 1) is a versatile, compact and convenient solution for your RC vehicles. Designed for the HSP RC4, this integrated unit combines a brushed ESC, receiver, and LED light controller for streamlined installation and simplified wiring. Enjoy the waterproof protection and reliable performance for any of your RC adventures.

Features
  • Waterproof design for all-weather conditions
  • Integrated 2.4GHz receiver for simplified setup
  • Built-in LED light controller for added realism
  • 40A continuous current handling for brushed motors
  • Compatible with 2-3S LiPo or 5-9 NiMH batteries
  • 6V @3A BEC output for reliable servo operation
  • Suitable for 1/10 scale RC cars and trucks
  • Genuine FlySky product for HSP
Included Items
  • 1x HSP RC4 1040 Waterproof Brushed ESC w/ Receiver & LED Light Controller (3 in 1)
Note

Brushless electric motors and ESCs have huge amounts of torque at any given RPM. Using too-tall gearing, or a vehicle that is too large/heavy, can result in damage and/or product failure. Please consult your manual and select gearing suitable for the vehicle and terrain, as damage caused by overloading or abuse is unlikely to be covered by the manufacturer's warranty. Always monitor your ESC and motor temperatures closely after modifying your system to ensure they stay within the safe operating limits.

Specifications
Length
44mm (1.73 in)
Width
30mm (1.18 in)
Height
16.7mm (0.66 in)
Weight
39g (1.38 oz)
Continuous/Peak Current
40A/200A
Waterproof
Yes
Motor Limit
Brushed Motors
BEC
6V @ 3A
Voltage Limit
2-3S LiPo / 5-9 Cells NiMH
Programmable
No
Scale
1/10th
Sensored
No

Receiver
Channels
6Ch
Suited Vehicle Type
Surface
Telemetry
No
Operating Frequency
2.4Ghz
Failsafe
When connection is lost with the remote the fail safe will stop the vehicle.
No
ESC (Electronic Speed Controller)
For Motor Type
Brushed
Max Voltage
11.1V
Waterproof Design
Yes
Burst Amps
200A
Continuous Amps
40A
Motor Connectors
Basic Bullet
Battery Connector
Deans
LVC
Low Voltage Cut-Off. Required for Lithium batteries.
Yes
Programmable
No
Cooling Method
Air
BEC Voltage
6V
Dual Motor
No
