Rovan 25kg Brake Servo w/ Servo Horn
Videos
Rovan 25kg Brake Servo w/ Servo Horn
Brand:
Rovan
|
SKU: 63054
Now $63.95
or 4 fortnightly payments of $15.99 with
Heavy-duty 25kg digital coreless servo for throttle/brake, fits most 1/5 scale trucks and buggies. Genuine Rofun product.
- Heavy-duty digital coreless servo for throttle/brake
- 25.0 kg-cm torque at 7.2V
- Aluminium case anodised in red
- Compatible with 6.0–8.4V voltage
- Fits Rovan Baja 5B, 5T, TLR 5ive-B, Losi 5ive-T, Losi Mini WRC and Losi DBXL
Pay later with
We'll send it today
When ordered within the next
hms
What does Next Dispatch mean?
Pay before 1:00pm Melbourne time on a dispatch day and your order ships the same day.
This is dispatch time, not delivery time — couriers still take their usual transit days.
Enter your suburb or postcode for delivery options
or
Enter your country for international delivery options
Compatible with
3 products.
See Compatibility
Description
The Rovan 25kg Brake Servo is a heavy-duty digital coreless servo for throttle/brake use, designed to fit most 1/5 scale trucks and buggies. It features an aluminium case anodised in red and is a genuine Rofun product.
Features
- Compatible with 6.0–8.4V voltage
- Aluminium case anodised in red
- Genuine Rofun product
- Will fit Rovan Baja 5B, 5T, TLR 5ive-B, Losi 5ive-T, Losi Mini WRC and Losi DBXL
Specifications
- Torque (6.0V): 17.25 kg-cm (239.5 oz/in)
- Torque (7.2V): 25.0 kg-cm (347.2 oz/in)
- Dead band: 1µs 1520µs / 330Hz
- Speed: 0.152 sec (6.0V) – 0.123 sec (8.4V)
- Operating Voltage: 6.0 ~ 8.4 DC Volts
- Weight: 59.3g (2.09 oz)
- Bearing Type: Ball Bearing x 2
- Motor Type: Coreless DC Motor
- Gear Type: Steel
- 25T Spline
- Working frequency: 1520µs / 333Hz
- Size: 40 x 21 x 40 mm (1.57 x 0.83 x 1.57")
- JR Connector, wire length: 265mm (10.4")
- Total Height (A): 45mm
- Body Width (B): 40mm
- Below Mount (C): 27.5mm
- Above Mount (D): 12.5mm
- Total Length (E): 56mm
- Total Width (F): 21mm
Included Items
- 1x Rovan 25kg Brake Servo Metal Geared Servo
- 1x Dual Sided Alloy Arm – Holes at 24mm, 19mm and 15mm from center
