Name: Tamiya MB-01 Volkswagen Golf II GTI 16V RC Car Electric 2WD 1/10 Scale Kit - Red Limited Edition
Brand: Tamiya
SKU: TAM-47516
Price: 298.36 AUD
Availability: OutOfStock

Overview

The Tamiya MB-01 Chassis Kit is the latest addition to the popular M-chassis series, known for its affordability, versatility, and ease of use. This 1/10 scale chassis builds upon the success of its predecessors, offering even more options for customisation and performance. With the ability to choose from three different wheelbases and either a front- or rear-wheel-drive system, the MB-01 allows for six unique setups to match your driving style and preferences.

The MB-01 chassis is designed for both beginners and experienced RC enthusiasts. Its user-friendly design makes it easy to assemble and maintain, while the wide range of compatible bodies opens up a world of possibilities for creating your dream RC car. The kit also includes the option to recreate the Volkswagen Golf II Rally Car, a legendary rally car that's sure to turn heads on the track. Whether you're looking for a fun and affordable entry into the world of RC cars or a versatile platform for serious competition, the Tamiya MB-01 Chassis Kit is the perfect choice.

This version comes with a limited edition, factory painted red body shell that lets you focus on the build.

Features

The MB-01 chassis is 2WD and offers three options for wheelbases and front- or rear- wheel drive system
Factory painted in a limited edition red
The attachment directions of final gears and steering linkage can be changed to switch between front- and rear- wheel drive
Motor mount and final gears sections are designed to facilitate assembly and maintenance
The 4-wheel double wishbone suspension has a symmetrical structure and friction shocks
Multi-link suspension is compatible with tyres featuring the same compound and rear tyre with toe-in as 4WD models, despite being a 2WD model
It features a gear ratio of 5.83:1 (when using kit-standard 29T pinion gear)
The model has 55mm diameter front tyres and 60mm diameter rear tyres, creating an authentic car stance
Fully licensed Volkswagen body shell
Genuine Tamiya Product

In the box

1x Tamiya 1/10 MB-01 Chassis Kit
1x 540 Sized Brushed Motor
1x Tamiya TBLE-02S Brushed ESC
1x 1/10 Volkswagen Golf II Painted Body Shell - Red

You'll need

1x Compatible 7.4V LiPo or 7.2V NiMH Battery
1x Compatible Charger
1x Compatible 1/10 Motor
1x Compatible 1/10 Servo
1x 2+ Channel Transmitter & Receiver
PS Series Polycarbonate Safe Paint
AA Batteries For Transmitter

Highlights

Centre Motor Mounting

The rear left mounted motor delivers power directly to the rear wheels via a driveshaft, providing a classic rear-wheel-drive driving experience with fast and responsive acceleration and exciting handling.
Additionally, this central motor mounting position creates better weight bias.

Compact Design

The MB-01 chassis is built with performance and customisability in mind. The MB-01 has a highly adjustable platform that's perfect for a variety of driving styles and can be adjusted to a wide range of wheelbase options, 209mm for short, 224mm for medium, and 239mm for long.
Additionally, you can set this versatile chassis up in a front wheel drive or rear wheel drive setting, making the MB-01 one of the most customisable machines!

Double Wishbone Suspension

The double wishbone suspension, with its symmetrical suspension arms, provides balanced handling and predictable performance. This design ensures consistent response and control, allowing you to hit the apex everything time.

Easy Maintenance

Maintenance is a breeze thanks to the MB-01's unitised motor mount. Secured with just two screws, it allows for quick and easy access to the motor for adjustments or upgrades.

Quick Battery Swaps

Designed for hassle-free battery replacement, the MB-01 features an innovative flip-up battery holder. This clever design allows you to quickly swap out batteries without any fuss, keeping the action going.

Three Section Steering System

The three-section steering system, operated by a long link rod connected to a rear-mounted servo, provides precise and responsive steering control for confident handling on a wide range of terrains.

TT-02 Differentials

The MB-01 chassis utilises the same durable 4-bevel differential gear as the TT-02 chassis, making access to replacement parts much easier. For those seeking further customisation, the differential can be upgraded with optional TT-02 ball differentials or oil-filled gear differentials.

Specifications

Length	383mm (15.07")
Width	170mm (6.69")
Height	138mm (5.43")
Wheelbase	239mm (9.41")
Weight	Varies
Chassis	On Road
Drivetrain	2WD
Suspension	Coil Over Shock Absorber
Motor	540 Sized Brushed Motor
ESC	Tamiya TBLE-02S Brushed ESC
