Vanquish VS4-10 Chassis Kit
Vanquish VS4-10 Chassis Kit
VS4-10 Chassis Kit — steel C-channel rails with aluminum tray, SCX10-II compatible, scale looks with full-strength molded components.
- High clearance C-channel steel chassis rails with molded front and rear cross members for ultimate strength
- Compatible with Axial SCX10-II axles and industry standard 3-gear transmissions
- Molded rock sliders with replaceable outer portion for custom build flexibility
- Dual servo mounts, winch line routing, and fuel cell built into molded components
- Aluminum battery and electronics tray ties all components together
The Vanquish Products VS4-10 Chassis Kit is made to provide a balance of scale looks and unhindered performance. This kit allows you to easily convert an Axial SCX10-II for greater performance or build from the ground up with the vast amount of axles on the market. The steel C-channel design provides scale detail; the molded front and rear cross members fill the chassis rails in the highest stress locations for ultimate strength and provide features like dual servo mounts, winch line routing, and a fuel cell. The molded rock sliders come with a replaceable outer portion for flexibility of custom builds. The VS4-10 Chassis kit is developed to work with the industry standard 3-gear transmissions found in most Axial SCX10-II and the VS4-10 Origin Limited. The aluminum battery and electronics tray helps to tie all the components together to make a unique and complete package.
- High Clearance C-Channel Steel Chassis Rails
- Machined Aluminum Panhard Mount Black Anodized
- Stainless Steel Panhard and Drag Link with molded rod ends and Steel Pivot Balls (VS4-10 and SCX10-II Axle Compatible)
- Aluminum Battery and Electronics Tray
- Vanquish Products Velcro Straps (2)
- Steel Pivot Balls included for Front and Rear 4-Link mounting at the skid plate to eliminate slop (8)
- Front and rear bumper mounts accept the popular bumpers with 43mm (1.70") post spacing
- Molded Chassis Components include:
- Front CMS with additional servo/winch mounting location, winch line routing channel and integrated battery tray brace
- Front Chassis brace completely fills the steel chassis rails for added strength and chassis stiffness
- Skid plate with smooth transitions to eliminate catching points at critical locations — no unnecessary bumps
- Transmission spacer to accommodate longer can motors and avoid interference with rear upper 4-link
- Chassis side guards and high clearance rock sliders tied to the aluminum battery tray for increased stiffness
- Rear chassis brace and fuel cell incorporating the rear bumper mounts, filling the C-Channel chassis rails for added strength and chassis stiffness
- Shock Towers with integrated body post mounts
- Wide variety of body posts included to match the common heights of popular body configurations on the market
- Black oxide hardware included
- 4x Body clips included
- Highly detailed instructions included for chassis assembly
Using a Dig will also require the VS4-10 Angle Servo Bracket (VPS01027).
