Tamiya DF-03 Dark Impact RC Buggy Electric 4WD 1/10 Kit
Tamiya DF-03 Dark Impact RC Buggy Electric 4WD 1/10 Kit
Tamiya DF-03 Dark Impact RC Body: A Powerful and Agile Buggy for Off-Road Adventures!
Perfect for all skill levels
Compatible with a wide range of brushed and brushless electronics
Compatible with a wide range of upgrade parts
Highly customisable
Adjustable chassis length
This kit comes without a Servo, Battery, Charger, or Transmitter and will come with an unpainted body that may require cutting and drilling.
The Tamiya Dark Impact 4WD Buggy is a 1/10 scale off-road machine designed for those who crave speed, agility, and performance. This versatile and durable buggy is ready to tackle any terrain, from smooth tracks to challenging off-road courses. The Dark Impact features a mid-rear mounted motor and longitudinally mounted battery for optimal balance and jumping capabilities, making it perfect for high-flying action.
The DF-03 chassis provides a solid foundation for the Dark Impact's impressive performance. The durable monocoque bathtub frame houses the heavy battery and R/C mechanism components low and central for optimal vehicle balance. Even the oil dampers are located within the wheelbase for greater stability and cornering performance. Compact gearboxes are equipped with ball differentials, and the propeller shaft directly links to the front bevel gear to minimize power loss during transmission. The 4-wheel double wishbone suspension with long suspension arms provides excellent shock absorption and a wide range of tuning options.
With its combination of powerful performance, durable construction, and versatile features, the Tamiya Dark Impact 4WD Buggy is the perfect choice for RC enthusiasts of all skill levels.
High-performance 1/10 4WD buggy chassis designed for off-road running
4-wheel independent double wishbone suspension with CVA oil dampers and extra-long suspension arms
Sealed differential gearbox for protection and smooth operation
Full ball bearings throughout the drivetrain for efficiency and reduced friction
Includes a 540 type motor for ample power
Newly designed off-road tyres and wheels with larger diameter, width, and tread pattern for excellent performance on hard dirt tracks
High-Density Spike Tyres K (4WD/Front, 62/25) and High-Density Spike Tyres K (Rear, 62/35) provide optimal grip and traction
Large Dish Wheels (4WD/Front, 62/25) and Large Dish Wheels (Rear 62/35) offer durability and a stylish look
2.94 internal gear ratio for a balance of speed and acceleration
Genuine Tamiya Product
Length: 387mm (15.24")
Width: 250mm (9.84")
Height: 145mm (5.71")
Wheelbase: 272mm (10.71")
Weight: 1156g (2.55 lbs)
Chassis: Off-Road (DF-03 Chassis Type)
Drivetrain: 4WD
Suspension: Oil Filled Coil Over Shock Absorbers
Motor: Tamiya 540 Sized Brushed Motor
ESC: Tamiya Brushed ESC
1x 1/10 DF-03 Dark Impact 4WD Electric Off Road RC Buggy Kit
1x 540 Sized Brushed Motor
1x Tamiya Brushed ESC
1x Compatible 7.4V LiPo or 7.2V NiMH Battery
1x Compatible Charger
1x Compatible 1/10 Scale Servo
1x 2+ Channel Transmitter & Receiver
Polycarbonate Compatible Paint
AA Batteries For Transmitter
-
Suited Motor/ESC Type
- Electric
-
Spur Gear
- 78T
-
Max LiPo Power
- 2S (7.4v)
-
Wheel Hex Size
- 12mm
-
Pinion Gear
- 26T
-
Front Shock Oil
- 400cSt
-
Rear Shock Oil
- 400cSt
-
Battery Connector
- Tamiya
-
Completion
- Kit
-
Drivetrain
- 4WD
-
Max LiPo Power
- 2S (7.4v)
-
On/Off Road
- Off Road
-
Chassis Type
- Buggy
-
Power Source
- Electric Brushed
-
Skill Level
- Intermediate
-
Scale
- 1/10
