Tamiya M-05 Ver II Pro RC On Road Chassis Electric 2WD 1/10 Scale Kit

Tamiya M-05 Ver II Pro RC On Road Chassis Electric 2WD 1/10 Scale Kit

Tamiya M-05 Ver II Pro RC On Road Chassis Electric 2WD 1/10 Scale Kit

Brand: Tamiya | MPN: 58593
discontinued
Description

The Tamiya M-05 M-Chassis platform receives a significant makeover with the M-05 Version II Pro. The M-05 chassis, released in 2009, has been a favourite platform for M-chassis club racers for years. The new tweaks and enhancements take advantage of new battery technologies as well as tried-and-true suspension tweaks used in many of Tamiya's touring car platforms. It features several upgrades to improve balance and lower the chassis' centre of gravity, using a variety of option parts to make it a highly drivable radio control car.

Thanks to the redesigned frame and the new motor mount placing the motor position closer to the centre of the chassis, it offers precision handling.

Features
  • Compatible with square-shaped battery packs
  • Chassis, D parts (arm stays and damper stays, etc.) and wheels have a Semi-Gloss Black metal-plated finish
  • Frame supports square-shaped battery packs and low-profile servos
  • One-Piece Suspension Arms (allow rebound stroke adjustment via grub screw)
  • The motor is fitted to a newly-designed mount and has been moved 4.5mm closer to the center of the chassis when compared to the original M-05
  • New aluminium motor mount designed specifically for the M-05 V.2 chassis
  • Improved weight distribution and sharper steering response
  • The servo attachment position has been shifted 8mm downwards to secure a lower center of gravity
  • DF-03 Heat Sink Bar Set
  • M-05 Full Ball Bearing Set
  • M-05 Aluminum Steering Posts (Blue)
  • M-05 Aluminum Turnbuckle Steering Rods (Blue)
  • M-05 Aluminum Servo Mount
  • CVA Super Mini Oil-Filled Shocks
Included Items
  • 1x Tamiya 1/10 M-05 Ver II Pro Electric On Road Chassis Kit
Required Items
  • 2Ch Transmitter & Receiver
  • Battery & Compatible Charger
  • Type 540 Motor
  • M-Chassis 60D Tyres
  • Body Shell
Specifications
Scale
1/10
Construction Type
Assembly kit
Length
S=300mm (11.8"), M/L=307mm (12.0")
Width
165mm (6.49")
Wheelbase
S=210mm (8.26"), M=225mm (8.85"), L=239mm (9.40")
Tyre Tread
138mm (5.43") Front & Rear
Monocoque Frame
Drivetrain
Front-Wheel 2WD
Differential
3-Bevel Differential Gear
Steering
3-Piece Tie-Rod
Suspension
Fully independent double wishbone
Shocks
CVA Super Mini Oil Dampers (Clear)
Gear Ratio
5.8:1 (Adjustable)

RC Car
Scale
1/10
Completion
Kit
Skill Level
Intermediate
Power Source
Electric
Chassis Type
Car
On/Off Road
On Road
Drivetrain
2WD
Factory Specs
Rear Shock Oil
200cSt, 300cSt, 400cSt, 500cSt, 600cSt, 700cSt, 800cSt, 900cSt, 1000cSt
Pinion Gear
20T, 21T
Wheel Hex Size
12mm
