Hobbywing Xerun AXE Plus R3 135A Brushless ESC
Hobbywing Xerun AXE Plus R3 135A Brushless ESC
Hobbywing XeRun AXE Plus R3 135A ESC: Packed With Features Like FOC Drive, Turbo Timing and more!
High-power rock crawler ESC with 135A continuous current
Supports up to 6S LiPo batteries for increased power
FOC drive system for smooth, quiet, and precise control
Advanced features including drag brake, hill hold, and adjustable parameters
Waterproof and dustproof with an IP67 rating for all-weather use
The Hobbywing XeRun AXE Plus R3 135A ESC is a high-power, waterproof brushless electronic speed control designed to elevate your rock crawling experience. This ESC offers smooth control, high torque output, and advanced features like FOC drive and adjustable parameters, making it ideal for tackling challenging off-road terrains. With support for up to 6S LiPo batteries, the XeRun AXE Plus R3 delivers ample power for conquering steep inclines and obstacles. The FOC drive system provides smooth, quiet, and precise control, while smart torque output ensures effortless hill climbing and descending. The IP67 waterproof and dustproof rating guarantees reliable performance in any weather condition. The built-in Bluetooth connectivity allows you to easily adjust parameters, monitor data, and upgrade firmware via the Hobbywing mobile app. With its advanced features and robust design, the Hobbywing XeRun AXE Plus R3 135A ESC is the ultimate choice for serious rock crawling enthusiasts.
Supports high-voltage applications with up to 6S LiPo batteries
Compact design for easy installation in various crawler builds
Compatible with all Axe R2 motors
Dual external control channels for real-time parameter adjustment
FOC drive system provides smooth, quiet, and linear power delivery
Smart torque output for effortless hill climbing and descending
Smart fan start-stop function for efficient cooling and noise reduction
IP67 waterproof and dustproof rating for reliable performance in challenging conditions
Super internal BEC with a maximum output current of 15A and adjustable voltage (6V/74V/84V)
Built-in Bluetooth for connecting to the Hobbywing mobile app for parameter setting, data reading, and firmware upgrades
Real-time data function allows monitoring of throttle, voltage, current, temperature, and speed
Built-in data logging function records up to 10 minutes of run data
Compatible with Axe R2 motors (540/540L/550) and Axe R3 motors (4274)
Supports Flysky i-BUS2 telemetry for real-time parameter adjustment and data viewing on compatible Flysky remote controllers
Offers a wide range of adjustable parameters, including 24-degree adjustable Turbo timing
Genuine Hobbywing product
Length: 49.5mm (1.95")
Width: 37.9mm (1.49")
Height: 32.8mm (1.29") (Height with fan)
Weight: 126.5g (4.46oz) (Including the weight of input line)
Continuous/Peak Current: 135A/600A
Waterproof: Yes
Motor Limit: Only supports XeRun AXE R2/R3 motors
BEC: Switch Mode 6V/7.4V/8.4V @ 6A
Voltage Limit: 2-6S LiPo
Programmable: Yes (via built-in Bluetooth)
Scale: 1/10th, 1/8th, 1/6th
Sensored: Yes
1x Hobbywing XeRun AXE Plus R3 135A ESC
-
Burst Amps
- 600A
-
Continuous Amps
- 135A
-
For Motor Type
- Brushless Sensored
-
Motor Connectors
- Bare Wires
-
Battery Connector
- XT60
-
BEC Voltage
- 8.4V, 6V, 7.4V
-
Dual Motor
- No
-
Cooling Method
- Fan
-
Waterproof Design
- Yes
-
Programmable
- Yes
-
LVCLow Voltage Cut-Off. Required for Lithium batteries.
- Yes
-
Max Voltage
- 22.2V
