Yeah Racing

Yeah Racing Black Aluminium Low Profile Coreless 10kg 8.4v Titanium & Copper Geared Servo

Part no. YE-0033BK

DiscontinuedNo reviews yet
1 / 3
1 / 3

Videos

Videos

Overview

Note

Servos are powered by the ESC's output to the receiver. If you're using a higher-strength servo than the ESC can support (usually greater than 20kg), you may experience 'brown-outs' where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver smoothing the current delivery. However, in some cases, you may need to install an external BEC.

Specifications

Servo

SizeConventionally sized servo namesStandard
Gear MaterialTitanium & Copper
Servo Spline Count25Tooth
Waterproof CasingNo
Case MaterialAluminium
Drive Motor TypeCoreless
Rotational Degrees120° (Normal)
6V Torque kg/cmKilograms of torque at 25mm away from the center of the spline10
6V Sec/60 DegreesSeconds per 60 degrees of rotation0.09
Signal TypeDigital

Dimensions

Servo
Height (A)30.5mm
Body Length (B)40.8mm
Bottom to Under Mount (C)19.25mm
Top to Under Mount (D)10mm
Length (E)54.1mm
Width (F)20.2mm
