 Servos are powered by the ESC's output to the receiver. If you're using a higher-strength servo than the ESC can support (usually greater than 20kg), you may experience 'brown-outs' where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver smoothing the current delivery. However, in some cases, you may need to install an external BEC.
Yeah Racing Hackgear 33kg Coreless Servo SpecificationsTotal Height (A) = 43mm
Body Width (B) = 40mm
Below Mount (C) = 26mm
Above Mount (D) = 10.6mm
Total Length (E) = 54mm
Total Width (F) = 20mm
? Learn how to install a steering servo correctly to increase steering performance, and avoid stripping your servo gears out.
-
Total Width
- 20mm
-
Servo Spline Count
- 25Tooth
-
Top to Under Mount
- 10.6mm
-
Total Length
- 54mm
-
Body Length
- 40mm
-
Bottom to Under Mount
- 26mm
-
6V Sec/60 DegreesSeconds per 60 degrees of rotation
- .092
-
Total Height
- 43mm
-
Signal Type
- Digital
-
Case Material
- Aluminium
-
6V Torque kg/cmKilograms of torque at 25mm away from the center of the spline
- 33
-
Gear Material
- Steel
-
Waterproof Casing
- Yes
-
Drive Motor Type
- Coreless
-
SizeConventionally sized servo names
- Standard
