Yeah Racing Micro 3kg 7.4v Metal Geared Servo

Brand: Yeah Racing | SKU: YE-0039

discontinued

write a review

Loading compatibility information...

Description

&nbspServos are powered by the ESC's output to the receiver. If you're using a higher-strength servo than the ESC can support (usually greater than 20kg), you may experience 'brown-outs' where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver smoothing the current delivery. However, in some cases, you may need to install an external BEC.

Aluminium waterproof micro servo for use with Traxxas's TRX-4 or TRX-6 as the diff locking or gear change servo. Full aluminium case aids with heat dissipation.

Features

For: Traxxas TRX-4 TRX-6

Colour: Black

High-precision

IP67 Waterproof

Specifications

Material: Aluminium

Gear: Steel

Max Angle: 180°

Voltage: 5.0V~7.4V

Torque: 5.0V-2.5kg ,6.0V-3.2kg , 7.4V-4kg

Speed: 5.0V-0.12S ,6.0V-0.11S, 7.4V-0.10S

Connector Wire Length: JR 260mm

Servo Spline: 25T (micro style)

Dimension: 23mm*13mm*26mm

Weight: 22g

Total Height (A) = 30mm

Body Width (B) = 23mm

Below Mount (C) = 15mm

Above Mount (D) = 13mm

Total Length (E) = 30mm

Total Width (F) = 13mm

How To: Install a Servo

In this video, Hamish gives a step-by-step guide on installing a Servo and how to avoid stripping your servo gears.

Specifications

Servo

Servo Spline Count: 25Tooth
Total Length: 30mm
Total Width: 13mm
Bottom to Under Mount: 15mm
Top to Under Mount: 13mm
Total Height: 30mm
Body Length: 23mm
Rotational Degrees: 180°
6V Sec/60 Degrees Seconds per 60 degrees of rotation: 0.11
Signal Type: Digital
Case Material: Aluminium
6V Torque kg/cm Kilograms of torque at 25mm away from the center of the spline: 2.5
Gear Material: Steel
Waterproof Casing: Yes
Drive Motor Type: Brushless
Size Conventionally sized servo names: Micro
