Reefs RC Aluminium 179 Smart Micro 13kg 8.4V Brushless Metal Gear Servo/Winch - Black

Reefs RC Aluminium 179 Smart Micro 13kg 8.4V Brushless Metal Gear Servo/Winch - Black image 100883

Reefs RC Aluminium 179 Smart Micro 13kg 8.4V Brushless Metal Gear Servo/Winch - Black image 100884

Reefs RC Aluminium 179 Smart Micro 13kg 8.4V Brushless Metal Gear Servo/Winch - Black

Brand: Reefs RC | SKU: REEFS129

2 in stock

write a review

$164.89

Reefs RC 179 Smart Brushless Micro Servo 12.9kg RC Servo: High torque, high speed, and programmable.

High torque of 12.9 kg-cm
Programmable with Reefs RC software
Magnetic angle sensor for precise control
Durable metal and steel gears with CNC aluminium casing
Compact size suitable for micro RC vehicles

Pay later with

We'll send it today

When ordered within the next hms

Description

The Reefs RC 179 Smart Brushless Micro Servo is a top-tier choice for RC enthusiasts seeking high performance and reliability in a compact form. This brushless micro servo boasts impressive torque and speed, making it ideal for demanding applications. With a voltage range of 6V to 8.4V, it delivers consistent power and performance across various conditions.

Designed with durability in mind, the 179 Smart features metal and steel gears and a CNC aluminium casing, ensuring it can withstand rigorous use. The programmable design allows for customisation to meet specific needs, whether used as a standard servo or a winch. The magnetic angle sensor and pulse width modulation control offer precise and responsive control, enhancing the overall driving experience. Whether you're a seasoned RC hobbyist or a newcomer, the Reefs RC 179 Smart Brushless Micro Servo is a reliable and powerful addition to your RC setup.

Features

High torque and speed brushless servo
Strong torque @ 12.9 kg-cm (179 oz-in) and fast speed of 0.06 sec @ 8.4V
Programmable with Reefs RC software
Magnetic angle sensor for precise control
Pulse width modulation control
Voltage range: 6V - 8.4V
No mechanical angle limit
Metal and steel gears with CNC aluminium casing
2 ball bearings for smooth operation
22AWG wires
Genuine Reefs RC product

Specifications

Torque(6.0V): 9.7 kg-cm (135 oz-in)
Torque(7.4V): 11.5 kg-cm (159 oz-in)
Torque(8.4V): 12.9 kg-cm (179 oz-in)
Speed: 0.09 sec (6.0V), 0.07 sec (7.4V), 0.06 sec (8.4V)
Operating Voltage: 6V - 8.4V
Weight: 21g (0.74oz)
Bearing Type: 2 Ball Bearings
Motor Type: Brushless Motor
Gear Type: Metal and Steel Gears
Size: 23x12x27.5mm (0.90x0.47x1.08")

Included Items

1x Reefs RC 179 Smart Brushless Micro Servo

Note

BEC is not required but recommended for maximum performance
Reefs RC LINK required for programming (optional)
Consult the manual for programming and maintenance

Specifications

Servo

Total Length: mm
Total Width: mm
Drive Motor Type: Brushless
Top to Under Mount: mm
8.4V Sec/60 Degrees: 0.06
Input Voltage Range: 7.4V, 6V, 8.4V
Rotational Degrees: 360°
8.4V Torque kg/cm: 13
Signal Type: Digital
Case Material: Aluminium
6V Torque kg/cm Kilograms of torque at 25mm away from the center of the spline: 10
Gear Material: Steel
Waterproof Casing: Yes
Servo Spline Count: 25Tooth
6V Sec/60 Degrees Seconds per 60 degrees of rotation: 0.09
7.4V Torque kg/cm: 12
Total Height: mm
7.4V Sec/60 Degrees: 0.07
Body Length: mm
Bottom to Under Mount: mm
Size Conventionally sized servo names: Micro
