Reefs RC Aluminium 99Micro 8.3kg 8.4V Metal Gear Servo - Black
Reefs RC Aluminium 99Micro 8.3kg 8.4V Metal Gear Servo - Black
Brand:
Reefs RC
|
SKU: REEFS25
$109.99
Pay later with
We'll send it today
When ordered within the next
hms
What does Next Dispatch mean?
Pay before 1:00pm Melbourne time on a dispatch day and your order ships the same day.
This is dispatch time, not delivery time — couriers still take their usual transit days.
Description
No description
Specifications
Servo
-
Height (A)
- 31.71mm
-
Body Length (B)
- 23.15mm
-
Bottom to Under Mount (C)
- 20.42mm
-
Top to Under Mount (D)
- 11.75mm
-
Length (E)
- 32.07mm
-
Width (F)
- 12.07mm
-
SizeConventionally sized servo names
- Micro
-
Gear Material
- Metal
-
Waterproof Casing
- Yes
-
Servo Spline Count
- 25Tooth
-
Input Voltage Range
- 6V, 7.4V, 8.4V
-
6V Torque kg/cmKilograms of torque at 25mm away from the center of the spline
- 6.4
-
6V Sec/60 DegreesSeconds per 60 degrees of rotation
- 0.11
-
7.4V Torque kg/cm
- 7.1
-
7.4V Sec/60 Degrees
- 0.09
-
8.4V Torque kg/cm
- 8.3
-
8.4V Sec/60 Degrees
- 0.08
-
Signal Type
- Digital
-
Drive Motor Type
- Brushed
-
Case Material
- Aluminium
-
Rotational Degrees
- 120° (Normal)
