Reefs RC Aluminium BEAST 1000 1/5 Scale 78kg 8.4V Brushless Metal Gear Servo with 15T Horns - Black
Reefs RC Aluminium BEAST 1000 1/5 Scale 78kg 8.4V Brushless Metal Gear Servo with 15T Horns - Black
Brand:
Reefs RC
|
SKU: REEFS102
$518.88
Reefs RC Beast 1000 1/5th Scale 77kg RC Servo: High torque, high speed, and waterproof.
- High torque and speed for superior performance
- Strong torque @ 77.8 kg-cm and fast speed of 0.08 sec @ 8.4V
- Submarine waterproof with 7-point seals
- Magnetic angle sensor for precise control
- Durable steel gears and CNC aluminium casing
Add to Wishlist
Description
Features
- High torque and speed brushless servo
- Strong torque @ 77.8 kg-cm (1080 oz-in) and fast speed of 0.08 sec @ 8.4V
- Submarine waterproof with 7-point seals
- Magnetic angle sensor for precise control
- Pulse width modulation control
- Voltage range: 4.8V - 8.4V
- No mechanical angle limit
- Steel gears and CNC aluminium casing
- 5 ball bearings for smooth operation
- 22AWG wires
- Genuine Reefs RC product
Specifications
- Torque(6.0V): 57.6 kg-cm (800 oz-in)
- Torque(7.4V): 64.8 kg-cm (900 oz-in)
- Torque(8.4V): 77.8 kg-cm (1080 oz-in)
- Speed: 0.11 sec (6.0V), 0.095 sec (7.4V), 0.08 sec (8.4V)
- Operating Voltage: 4.8V - 8.4V
- Weight: 285g (10oz)
- Bearing Type: 5 Ball Bearings
- Motor Type: Brushless Motor
- Gear Type: Steel Gears
- Size: 65.8x30x59mm (2.59x1.18x2.32")
Included Items
- 1x Reefs RC Beast 1000 1/5th Scale Servo
- 1x Reefs RC Single Horn
- 1x Reefs RC Double Horn
- 1x Servo Horn Screw 3.5x8mm
- 3x 3x16mm Cap Head Screws for end of horns
- 4x 2mm Horn Clamping Cap Head Screws
Note
- BEC is not required but recommended for maximum performance
- Consult the manual for waterproof standards and maintenance
Specifications
Servo
-
Total Length
- mm
-
Total Width
- mm
-
Drive Motor Type
- Brushless
-
Top to Under Mount
- mm
-
8.4V Sec/60 Degrees
- 0.08
-
Input Voltage Range
- 7.4V, 6V, 8.4V
-
Rotational Degrees
- 120° (Normal)
-
8.4V Torque kg/cm
- 78
-
Signal Type
- Digital
-
Case Material
- Aluminium
-
6V Torque kg/cmKilograms of torque at 25mm away from the center of the spline
- 57
-
Gear Material
- Steel
-
Waterproof Casing
- Yes
-
Servo Spline Count
- 15Tooth
-
6V Sec/60 DegreesSeconds per 60 degrees of rotation
- 0.11
-
7.4V Torque kg/cm
- 65
-
Total Height
- mm
-
7.4V Sec/60 Degrees
- 0.095
-
Body Length
- mm
-
Bottom to Under Mount
- mm
-
SizeConventionally sized servo names
- 1/5
