Reefs RC Aluminium Triple7 Standard 60kg 14V Direct Power Brushless Metal Gear Servo - Black
Reefs RC Aluminium Triple7 Standard 60kg 14V Direct Power Brushless Metal Gear Servo - Black
Brand:
Reefs RC
|
MPN: REEFS777
$249.99
or 4 fortnightly payments of $62.50 with
Pay later with
Enter your suburb or postcode for delivery options
or
Enter your country for international delivery options
Description
No description
Specifications
Servo
-
SizeConventionally sized servo names
- Standard
-
Gear Material
- Metal
-
Servo Spline Count
- 25Tooth
-
Waterproof Casing
- Yes
-
Input Voltage Range
- 10V, 11V, 12V, 14V
-
Case Material
- Aluminium
-
Height (A)
- 46.92mm
-
Body Length (B)
- 40.07mm
-
Bottom to Under Mount (C)
- 29.49mm
-
Top to Under Mount (D)
- 17.52mm
-
Length (E)
- 54.07mm
-
Width (F)
- 20.17mm
-
Drive Motor Type
- Brushless
-
Rotational Degrees
- 120° (Normal)
-
11V Torque kg/cm
- 47.95
-
11V Sec/60 Degrees
- 0.10
-
12V Torque kg/cm
- 50.40
-
12V Sec/60 Degrees
- 0.08
-
Signal Type
- Digital
Reviews
(2)
5 out of 5 stars
3 months ago
josh
H
No review text provided.
5 out of 5 stars
5 months ago
Rudy
B
Excellent service. Servo is great. Highly recommend Hobbies Direct
Questions & Answers
(1)
Have a question, or an answer? Weigh in here. Our team and other owners both reply.
0
Edwin
2 weeks ago
Hi, is this compatible to a trx4 1:10 bronco?
0
Daniel
2 weeks ago
Hi Edwin, Being a standard-size servo with a 25t Horn, Yes. However, with the power output being over 20 kg, you will definitely need to do something to provide the ESC some additional power to stop brownouts. With a servo of this calibre, you will likely need to wire in an external BEC, as a simple glitch buster won't cut it.
