Hi, is this compatible to a trx4 1:10 bronco?

Name: Reefs RC Aluminium Triple7 Standard 60kg 14V Direct Power Brushless Metal Gear Servo - Black
Brand: Reefs RC
SKU: RFS-REEFS777
Price: 249.99 AUD
Availability: OutOfStock
Rating: 5 (2 reviews)

Hi Edwin, Being a standard-size servo with a 25t Horn, Yes. However, with the power output being over 20 kg, you will definitely need to do something to provide the ESC some additional power to stop brownouts. With a servo of this calibre, you will likely need to wire in an external BEC, as a simple glitch buster won't cut it.

Reefs RC Aluminium Triple7 Standard 60kg 14V Direct Power Brushless Metal Gear Servo

Specifications

Servo

SizeConventionally sized servo names	Standard
Gear Material	Metal
Servo Spline Count	25Tooth
Waterproof Casing	Yes
Input Voltage Range	10V, 11V, 12V, 14V
Case Material	Aluminium
Height (A)	46.92mm
Body Length (B)	40.07mm
Bottom to Under Mount (C)	29.49mm
Top to Under Mount (D)	17.52mm
Length (E)	54.07mm
Width (F)	20.17mm
Drive Motor Type	Brushless
Rotational Degrees	120° (Normal)
11V Torque kg/cm	47.95
11V Sec/60 Degrees	0.10
12V Torque kg/cm	50.40
12V Sec/60 Degrees	0.08
Signal Type	Digital

Reviews (2)

5.0

Based on 2 reviews

5 stars2
4 stars0
3 stars0
2 stars0
1 star0

josh h
Verified buyer
24 May 2026
Rudy B
Verified buyer
16 Mar 2026
Excellent service. Servo is great. Highly recommend Hobbies Direct

Questions & Answers (1)

Have a question, or an answer? Our team and other owners both reply.

Edwin23 Aug 2026
Question: Hi, is this compatible to a trx4 1:10 bronco?
DanielStaff24 Aug 2026
Answer:
Hi Edwin, Being a standard-size servo with a 25t Horn, Yes. However, with the power output being over 20 kg, you will definitely need to do something to provide the ESC some additional power to stop brownouts. With a servo of this calibre, you will likely need to wire in an external BEC, as a simple glitch buster won't cut it.
