Savox Orange Aluminium SA-1256TG Plus Standard 36kg 6V Coreless Metal Geared Servo
Part no. SA-1230SG-PLUS
Sold outWrite a review
$146.62
or 4 fortnightly payments of $36.66 with afterpay
Savox SA-1256TG Plus coreless digital servo — 36 kg torque at 6V with steel gears and Sanwa SSR compatibility.
- 36 kg torque at 6V with coreless motor for exceptional speed and power
- Extremely strong unique steel gears for long life and durability
- Soft Start and Sanwa SSR compatibility via the "Plus" series upgrade
- Ideal for rock crawlers, monster trucks, and large scale aircraft
Ordered 3 Nov · we're waiting on our supplier
Checking delivery dates…
60-day returns · 12,000+ 5-star reviews · 03 5292 1101 ·
In stock now: similar
- Savox Orange Aluminium 12kg 6V Standard Plus Titanium Geared Servo
Now $93.26
was $133.23Save 30%
Overview
Servos are powered by the ESC's output to the receiver. If you're using a higher-strength servo than the ESC can support (usually greater than 20 kg), you may experience 'brown-outs' where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver, smoothing the current delivery. However, in some cases, you may need to install an external BEC.
The Savox SA-1256TG Plus High Torque, High Voltage Digital Servo stands as a pinnacle of servo performance, offering exceptional speed and high torque, making it a versatile choice for a wide range of applications. The "Plus" series elevates this servo further with advanced features like Soft Start and Sanwa SSR compatibility for enhanced control and expanded compatibility.
Features
- Extremely strong unique steel gears ensure long life and durability.
- Ideal for steering on rock crawlers, monster trucks, and large scale aircraft.
- Slightly taller case design.
Specifications
| Torque @ 4.8V | 30.0 kg / 416.6 oz-in |
|---|---|
| Torque @ 6V | 36.0 kg / 499.9 oz-in |
| Speed @ 4.8V | 0.20 sec/60 deg |
| Speed @ 6V | 0.16 sec/60 deg |
| Dimensions L x W x H (mm): 40.3 x 20.2 x 44.9 | |
| Weight | 79.0 g |
| Total Height (A) | 44.9 mm |
| Body Width (B) | 40.3 mm |
| Below Mount (C) | 31.2 mm |
| Above Mount (D) | 12.8 mm |
| Total Length (E) | 54 mm |
| Total Width (F) | 20.2 mm |
| Operating Temperature | 14° – 122°F (-10° – 50°C) |
| Running Current (no load) | 180 mA @ 4.8V, 250 mA @ 6.0V |
| Stall Current (at locked) | 4200 mA @ 4.8V, 5300 mA @ 6.0V |
| Idle Current | 5 mA @ 4.8V, 5 mA @ 6.0V |
| Wire Length | 200 ±5 mm |
| Output Gear Spline | 25 Tooth |
| Bearings | 2BB |
| Operating Travel | 100° (1000–2000 µs) |
| Neutral Position | 1500 µs |
| Pulse Width Range | 800–2200 µs |
| Maximum Travel | Approx. 130° (900–2100 µs) |
| Refresh Rate | 333 Hz |
| Motor Type | Coreless |
Servo
| Size | Standard |
|---|---|
| Gear Material | Metal |
| Servo Spline Count | 25Tooth |
| Waterproof Casing | Splash Proof |
| Case Material | Metal |
| Height (A) | 44.9mm |
| Body Length (B) | 40.3mm |
| Bottom to Under Mount (C) | 31.2mm |
| Top to Under Mount (D) | 12.8mm |
| Length (E) | 54mm |
| Width (F) | 20.2mm |
| Drive Motor Type | Coreless |
| Rotational Degrees | 120° (Normal) |
| 6V Torque kg/cm | 36 |
| 6V Sec/60 Degrees | 0.11 |
| Signal Type | Digital |
