Tamiya 1/10 CC-02 Land Rover Defender 90 Electric Off Road RC Rock Crawler Kit

The 1990 Land Rover Defender 90 (originally on the CC-01 chassis) makes its way to the CC-02 chassis!

The Defender 90 is a legendary Land Rover off-road car, and its roots go back to 1948. Based on differences in wheelbases, this car has three types – the Defender 90/110/130. This R/C model depicts a 3-door model with 93-inch wheelbase.

CC-02 Chassis - Off Road, Evolved

Designed for a wide range of off-road scenes, including rocky terrain, the CC-02 chassis' ladder frame is inspired by full-size vehicles and is the base for its superior durability. A 4WD setup employs the motor longitudinally behind the front axle with a separated gearbox, transfer case, and propeller shafts transmitting power to the differential gears front and rear. Four-link rigid suspension is employed front and rear, with CVA oil dampers for all-encompassing control, even on tricky rock sections. This model comes with black wheels and grippy block pattern tyres.

• The unmistakable shape of the Defender 90 is precisely captured by the lightweight polycarbonate body, with additional attachment positions for chassis mounting.
• Compatible with x2 5mm diameter LEDs for the headlights and x6 5mm diameter LEDs for the rear.
• Includes separately moulded parts for grille, side mirrors, light shields and indicators.
• Black ABS resin wheels are matched with all-terrain semi-pneumatic tyres.
• Short drive shafts (P parts) transmit power to the front and rear differential gears.
• The CC-02 chassis with frame offers superior durability and uses front/rear coil spring suspension, an excellent compromise for off-road surfaces, including rocky terrain.
• Includes 540 Type brushed motor.
• A wide range of optional Hop-Up parts are available to customise the model.

• Scale: 1/10
• Construction Type: Assembly Kit
• Length: 429mm (16.8")
• Width: 200mm (7.87")
• Height: 215mm (8.46")
• Wheelbase: 242mm (9.52")
• Body Material: Polycarbonate
• Chassis Material: ABS Plastic
• Drive Type: 4WD
• Motor: 540-brushed type
• Terrain Use: Off-Road

• 7.2V NiMH Battery & Compatible Charger
• 4 x AA Batteries
• Standard Sized Servo
• Electronic Speed Controller (ESC)
• 2Ch Transmitter & Receiver
• Tamiya PS Paint
